Paneltronics Breaker 10 Amps A-Frame Magnetic Waterproof

Panel Seal/Waterproof “A” Frame Magnetic Circuit Breakers

• Branch AC or DC circuit breaker for Paneltronics electrical distribution panels

• Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers

• UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada

• Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)

• Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)


• Handle Color Metal with Silicon rubber seal

• Maximum Amperage 50 Amps

• Maximum Voltage /AIC 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)

• Rated Switch Cycles Rated Switch Cycles 10,000 actuations at rated current and voltage

• Electrical Hardware Screw 10-32 x 3/8″ pan combo head (P/N 197-188)

• Mounting Hardware Hex nut 1/2-32 (supplied with circuit breaker)

• Lockwasher 1/2″ internal tooth (supplied with circuit breaker)

• Optional Boot Black silicone rubber (P/N 048-015)
