Maretron Micro/Mid Field Attachable Connector 90 Female $30.00

Maretron Micro Double-Ended Cordset 5 Meter

$55.00

Connection Gender = Male-Female | Data Interface = NMEA 2000 | Cable Length (Meters) = 5m | NMEA 2000 Connectors = Backbone/Drop Cables

In stock

Free USA shipping on all orders over $150*

  • 30 days easy returns
  • Order yours before 1:00pm for same day dispatch
Guaranteed Safe Checkout

Mechanical

  • Contact Carrier Mat/Color: Thermoplastic PUR/Blue-Gray
  • Molded Body Mat/Color: Thermoplastic PUR/Blue-Gray
  • Contact Mat/Plating: Brass/Gold
  • Coupling Nut Mat/Plating: Brass/Nickel
  • Connector Outside Diameter: 0.59?Electrical
  • Current Rating: 4.0 Amps
  • Voltage Rating: 250 V
    Cable
  • Outer Jacket Mat/Color: PVC/Gray
  • Conductor Insulation Material: HDPE (data pair), SRPVC (power pair)
  • Number of Conductors: 4X22 AWG, 22 AWG Drain Wire
  • Shielding (3-Levels): FOIL (Overall), FOIL (Power Pair), FOIL (Data Pair)
    Environmental
  • Protection Class: IEC IP68, NEMA 1,3,4,6P
  • Temperature Rating: -40 deg C to 80 deg C to (-40 deg F to 176 deg F)
    Approvals
  • (Cable) UL: PLTC 75 deg C Sunlight Resistant E90625, AWM 80 deg C 300V
  • (Cable) CSA: CMX-OUTDOOR-CMG LL54185 75 deg C, AWM I/II A/B 80C 300V FT4
  • NMEA: NMEA 2000 Approved

    • Additional information

    Weight 0.74 lbs
    Dimensions 8 × 8 × 1 in
    UPC

    873804001555
    Mfg. Part Number

    CM-CG1-CF-05.0
    Manufacturer

    Country of Origin

    Harmonization Code

    Quick Guide Literature (pdf)
    Warning: Trying to access array offset on value of type bool in /home/180sails/public_html/wp-content/themes/shoptimizer/functions.php on line 826
    Owners Manual (pdf)
    Warning: Trying to access array offset on value of type bool in /home/180sails/public_html/wp-content/themes/shoptimizer/functions.php on line 826
    Brochure Literature (pdf)
    Warning: Trying to access array offset on value of type bool in /home/180sails/public_html/wp-content/themes/shoptimizer/functions.php on line 826
    Installation Guide (pdf)
    Warning: Trying to access array offset on value of type bool in /home/180sails/public_html/wp-content/themes/shoptimizer/functions.php on line 826
    Video Urls
    Prop 65

    Reviews

    There are no reviews yet.

    Be the first to review “Maretron Micro Double-Ended Cordset 5 Meter”
    SKU: 33359 Category: Tag:
