Paneltronics SPDT (ON)/OFF/(ON) Start/Stop Rocker Switch – Momentary Configuration

$12.81

Color = Black | Throw/Pole = SPDT | Action = (On)/Off/(On)

Out of stock

Free USA shipping on all orders over $150*

  • 30 days easy returns
  • Order yours before 1:00pm for same day dispatch
Guaranteed Safe Checkout

Rocker Switch


  • UL Recognized and CSA Certified
  • Single Pole Non-Illuminated
  • Snap-in Mounting
  • Replacement Switches for Paneltronics’ Deluxe and Premier Panels

Specifications:

  • Maximum Contact Rating: 6 Amps @ 125VAC or 4 Amps @ 250VAC
  • Contacts: Silver Plated Copper
  • Terminals: Silver Plated Copper 1/4″ (6.3mm) Quick Connects
  • Operating Temperature: -4 deg F (-20 deg C) to 131 deg F (55 deg C)
  • Housing and Actuator: Black Thermoplastic
  • Flammability Rating: UL 94 V-2
  • Rated IEC 60529: IP40
  • Panel Thickness: 1/8″ (3.18mm)
  • Recommended Panel Cut-Out: 1.188″ (30.18mm) x 0.468″ (11.89mm)

Additional information

Weight0.1 lbs
Dimensions1 × 1 × 1 in
UPC

602290100059

Mfg. Part Number

Manufacturer

Country of Origin

Quick Guide Literature (pdf)
Owners Manual (pdf)
Brochure Literature (pdf)
Installation Guide (pdf)
