Jabsco Low Pressure Cyclone Centrifugal Pump – 24V

$564.99

Gallons Per Minute = 29.7 GPM | Max PSI = 8.7 | Volts = 24v

In stock

Free USA shipping on all orders over $150*

  • 30 days easy returns
  • Order yours before 1:00pm for same day dispatch
Guaranteed Safe Checkout

Low Pressure Cyclone Centrifugal Pump – 24V

Silent running. Single tool servicing. 2m (6 foot) suction lift when wet.

A range of Stainless Steel General Purpose Centrifugal pumps designed specifically for the marine and industrial markets. Typical applications would be for circulation applications such as hot water systems, livewell or bait tank installations.

Features:

  • Heavy duty robust design
  • Stainless steel construction
  • Long life DC motor
  • Silent running
  • Anti-clog impeller design
  • Long life mechanical seal
  • Single tool servicing

Specifications:

  • Pump Body: Stainless Steel
  • Port Size: 3/4″ pipe threads, available with NPTF threads
  • Flow: 110 Liters/Minute (29.7 gallons/min.)
  • Pressure: Up to 0.6 bar (8.7psi)
  • Impeller: Stainless Steel Anti-Clog Impeller Design
  • Shaft Seal: Mechanical
  • Maximum Current: 4.5 Amp
  • Fuse Size: 7 Amp
  • Motor: Continuously rated
  • Motor life 3500 hours
  • ISO 8846 Marine and USCG Regulations for Ignition Protection
  • ISO 8849 Marine Bilge Pump Standard

WarningWARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

Additional information

Weight7.2 lbs
Dimensions12 × 6 × 6 in
UPC

671880579384

Mfg. Part Number

Manufacturer

Country of Origin

Harmonization Code

Quick Guide Literature (pdf)
Owners Manual (pdf) Download
Brochure Literature (pdf)
Installation Guide (pdf)
Video Urls
Prop 65

WarningWARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.
