Blue Sea 5502100 Class T Fuse Block w/Insulating Cover – 225 to 400A

$99.83

Fuse Type = Class T | Type = Fuse Blocks

Out of stock

Free USA shipping on all orders over $150*

  • 30 days easy returns
  • Order yours before 1:00pm for same day dispatch
Guaranteed Safe Checkout

Class T Fuse Block with Insulating Cover – 225 to 400A

Allows the use of Class T fuses for fast acting circuit protection of inverters and other electronics

  • Four stud design provides ample access around connecting stud to install large cable lugs without obstruction from the fuse
  • Insulating cover satisfies ABYC/USCG insulation requirements
  • Cover breakouts allow wire access in any direction
  • Stud design ensures secure fuse mounting even with high heat
  • Stainless steel studs provide resistance to corrosion and high torque
  • One-piece stainless flange nuts ensure safe and secure connections
  • UL 94-V0 base resists high heat

Technical Specifications:

  • Cable Size: Up to 4/0 AWG
  • Ignition Protected: Yes
  • Maximum Amperage: 320A
  • Maximum Voltage: 160V DC
  • Fuse Mounting Blocks: Tin-Plated Copper
  • Terminal Stud Size: 5/16″-18 (M8)

WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Additional information

Weight1.8 lbs
Dimensions8 × 8 × 3 in
UPC

632085550219

Mfg. Part Number

Manufacturer

Country of Origin

Harmonization Code

Quick Guide Literature (pdf)
Owners Manual (pdf)
Brochure Literature (pdf)
Installation Guide (pdf)
